| TABLE |
1524 x 305 mm |
| TRAVEL | |
|---|
| Longitudinal |
800 mm |
| Cross |
400 mm |
| Vertical |
380 mm |
| SPINDLE | |
|---|
| Taper |
NT40# |
| Dia. of Quill |
100 mm |
| Spindle Travel |
127 mm |
| Spindle Nose to Table Surface |
80-483mm |
| Spindle Center to Column |
180-770mm |
| Main Motor for Inverting |
3.75 Kw |
| Inverter |
3.75 Kw |
| Variable Speed |
70 - 4200 R.P.M. |
| Quill Feeds Per. Rev. of Spindle |
0.004 - 0.008 - 0.15 mm |
| Feed Motro ( X, Y, Z - Axis ) |
0.375 KW / 0.375 KW / 0.2 KW |
| Feed Rate ( X, Y - Axis ) |
Min: 20 mm/min Max.: 2200 mm/min |
| Swivel Angle to Right & Left |
90° |
| Swivel Angle to Front & Back |
45° |
| Approximate Net Weight |
1550 Kgs |
